Alpha 1-4 LSCbasic
Universal benchtop unit in compact design for efficient lyophilization of samples
Ice condenser capacity
: 4 kg
Ice condenser temperature : -55 °C
Ice condenser temperature : -55 °C
![[Translate to English:]](/fileadmin/user_upload/christ/02_produkte/01_labor/_neu/1-2_lsc_basic/laboratory_alpha_1-2_lscbasic.jpg "[Translate to English:]")
Laboratory freeze-dryer
Small, powerful tabletop unit for efficient lyophilization for everyday use – now with intuitive control!
Alpha 1-2 LSCbasic
Drying manifold for eight round-bottom flasks, wide-neck filter bottles or ampoule distributors
Condenser capacity: 2,5 kg
Condenser temperature: –55 °C
| Controller | LSCbasic |
| Method | Double-chamber |
| Max. connections | 8 |
Alpha 1-2 LSCbasic
Three unheated shelves
Condenser capacity: 2,5 kg
Condenser temperature: –55 °C
| Controller | LSCbasic |
| Method | Double-chamber |
| Max. number of shelves | 3 |
| Shelf diameter | 200 mm |
| Shelf temperature | Unheated |
| Diameter of acrylic chamber | 240 mm |
Alpha 1-2 LSCbasic
Three unheated shelves, additional connections for eight round-bottom flasks, wide-neck filter bottles or ampoule distributors
Condenser capacity: 2,5 kg
Condenser temperature: –55 °C
| Controller | LSCbasic |
| Method | Double-chamber |
| Max. Max. number of shelves | 3 |
| Shelf diameter | 200 mm |
| Shelf spacing | 85 mm |
| Diameter of acrylic chamber | 240 mm |
| Max. Connections | 8 |
Alpha 1-2 LSCbasic
Stoppering device with two unheated shelves
Condenser capacity: 2,5 kg
Condenser temperature: –55 °C
| Controller | LSCbasic |
| Method | Double-chamber |
| Max. number of shelves | 2 |
| Shelf diameter | 200 mm |
| Shelf spacing | 70 mm |
| Max. capacity for 2R vials | 220 |
| Stoppering device | Yes |
Basic device
Compact, high-performance tabletop unit for effective lyophilisation of specimens in your everyday lab activities. The LSCbasic user interface makes the work very easy. You can choose from a wide range of configurations to adapt the freeze dryer optimally to your specific needs. The condenser temperature of –55 °C enables the drying of aqueous products.
Ice condenser capacity
2,5 kg
2,5 kg
Ice condenser temperature
-55 °C
-55 °C
Footprint
315 x 345 x 470 mm
315 x 345 x 470 mm
Product Specifications
| Ice condenser capacity | 2,5 kg |
|---|---|
| Ice condenser temperature | -55 °C |
| Dimensions of base model (W x H x D) | 315 x 345 x 470 mm |
| Weight | 32 kg |
| Communication port | USB, LAN |
| GWP Index | 2 |
Special Features
- 5.7“ color touchscreen with clear layout
- Manual or automatic process continuation
- Interactive graphical display of the system schematic
- Extensive messages (cause, action, effect)
- Maintenance intervals for vacuum pump and system
- Multiple language options
- Selectable units for temperature and pressure
- Integrated sublimation curve
- Automatic process sequences ensure reproducible results
- Process data acquisition and optional data exchange over USB or LAN
- EntryPackage: Powerful complete package at an attractive package price with short delivery time
Equipped with natural refrigerants*
As a leading manufacturer of freeze drying systems, we use natural refrigerants to provide sustainable and environmentally friendly freeze drying solutions. Our innovations help reduce environmental impact and build a greener future.
In 2009, we became one of the first manufacturers to convert our laboratory and pilot freeze dryers to nonflammable refrigerants. As a result, our freeze dryers have a particularly low Global Warming Potential (GWP) index.
* 50 Hz version, technichal changes reserved
Alpha 1-2 LSCbasic
Small, powerful tabletop unit for efficient lyophilization for everyday use – now with intuitive control!
